The 285TR offers multiple features to provide support, comfort, and pressure relief along with the other benefits of tilt-in-space technology. The chair height adjustment allows for over toilet use or can be used with a commode pan, making this chair a versatile answer for home or institutional use.
New & Notable
The 285TR, Rehab Shower/Commode Chair-Tilt, Recline, Seat Height Adjustment, has a stainless steel frame with a reclining back and tool-free, 4-way seat. The combination of tilt-in-space and recline easily accommodates complex positioning needs.
| Seat Width | 16″ | 18″ | 18″ | 20″ | 20″ | 22″ | 22″ |
| Weight Capacity | 350lbs. | 350lbs. | 350lbs. | 350lbs. | 350lbs. | 350lbs. | 350lbs. |
| Width between Arm Rests Flip-Up with Pad | 22″ | 22″ | 22″ | 22″ | 22″ | 22″ | 22″ |
| Width between Arm Rests – Arm Troughs | 20″ | 20″ | 20″ | 20″ | 20″ | 20″ | 20″ |
| Width between Arm Rests – Height Adjustable | 21.5″ | 21.5″ | 21.5″ | 21.5″ | 21.5″ | 21.5″ | 21.5″ |
| Seat Depth | 18″ | 18″ | 20″ | 18″ | 20″ | 18″ | 20″ |
| Seat Height From Floor to Top of Seat | 22″ – 25″ | 22″ – 25″ | 22″ – 25″ | 22″ – 25″ | 22″ – 25″ | 22″ – 25″ | 22″ – 25″ |
| Usable Seat Depth w/Solid Back | 16″ | 16″ | 18″ | 16″ | 18″ | 16″ | 18″ |
| Leg Rest Range – Gooseneck | 16″ – 20″ | 16″ – 20″ | 16″ – 20″ | 16″ – 20″ | 16″ – 20″ | 16″ – 20″ | 16″ – 20″ |
| Leg Rest Range – Gooseneck w/ Padded Footplate | 14.75″ – 18.75″ | 14.75″ – 18.75″ | 14.75″ – 18.75″ | 14.75″ – 18.75″ | 14.75″ – 18.75″ | 14.75″ – 18.75″ | 14.75″ – 18.75″ |
| Leg Rest Range – Elevating (Up) | 16.5″ – 23.5″ | 16.5″ – 23.5″ | 16.5″ – 23.5″ | 16.5″ – 23.5″ | 16.5″ – 23.5″ | 16.5″ – 23.5″ | 16.5″ – 23.5″ |
| Leg Rest Range – Elevating (Up) w/ Padded Footplate | 15.25″ – 22.25″ | 15.25″ – 22.25″ | 15.25″ – 22.25″ | 15.25″ – 22.25″ | 15.25″ – 22.25″ | 15.25″ – 22.25″ | 15.25″ – 22.25″ |
| Leg Rest Range – Elevating (Down) | 15.5″ – 22.5″ | 15.5″ – 22.5″ | 15.5″ – 22.5″ | 15.5″ – 22.5″ | 15.5″ – 22.5″ | 15.5″ – 22.5″ | 15.5″ – 22.5″ |
| Leg Rest Range – Elevating (Down) w/ Padded Footplate | 14.25″ – 21.25″ | 14.25″ – 21.25″ | 14.25″ – 21.25″ | 14.25″ – 21.25″ | 14.25″ – 21.25″ | 14.25″ – 21.25″ | 14.25″ – 21.25″ |
| Arm Height from Top of Seat – Flip Up w/Pad | 8″ | 8″ | 8″ | 8″ | 8″ | 8″ | 8″ |
| Arm Height from Top of Seat – Arm Troughs | 8.25″ | 8.25″ | 8.25″ | 8.25″ | 8.25″ | 8.25″ | 8.25″ |
| Arm Height from Top of Seat – Height Adjustable | 4″ – 14″ | 4″ – 14″ | 4″ – 14″ | 4″ – 14″ | 4″ – 14″ | 4″ – 14″ | 4″ – 14″ |
| Back Height from Top of Seat | 22″ | 22″ | 22″ | 22″ | 22″ | 22″ | 22″ |
| Gap Between Top of Seat and Bottom of Back | 4″ | 4″ | 4″ | 4″ | 4″ | 4″ | 4″ |
| Maximum Back Slack | 3″ | 3″ | 3″ | 3″ | 3″ | 3″ | 3″ |
| Seat to Back Angle | 0° – 40° | 0° – 40° | 0° – 40° | 0° – 40° | 0° – 40° | 0° – 40° | 0° – 40° |
| Tilt Range | 0° – 26° | 0° – 26° | 0° – 26° | 0° – 26° | 0° – 26° | 0° – 26° | 0° – 26° |
| Head Support Height Range – Top of Seat to Bottom of Cervical Support | 22.5″ – 30.5″ | 22.5″ – 30.5″ | 22.5″ – 30.5″ | 22.5″ – 30.5″ | 22.5″ – 30.5″ | 22.5″ – 30.5″ | 22.5″ – 30.5″ |
| Under Seat Height Clearance | 17.75″ | 17.75″ | 17.75″ | 17.75″ | 17.75″ | 17.75″ | 17.75″ |
| Under Seat Width Clearance | 14″ | 16″ | 16″ | 18″ | 18″ | 20″ | 20″ |
| Overall Min Width w/Adj. Height Armrests | 24″ | 26″ | 26″ | 28″ | 28″ | 30″ | 30″ |
| Overall Max Width w/Arm Troughs | 29″ | 31″ | 31″ | 33″ | 33″ | 35″ | 35″ |
| Overall Min Length | 42″ | 42″ | 42″ | 42″ | 42″ | 42″ | 42″ |
| Overall Max Length | 66″ | 66″ | 66″ | 66″ | 66″ | 66″ | 66″ |
| Back of Unit to Start of Commode Opening | 15″ | 15″ | 15″ | 15″ | 15″ | 15″ | 15″ |
| Turning Radius | 26.5″ | 26.5″ | 26.5″ | 26.5″ | 26.5″ | 26.5″ | 26.5″ |
| Seat Used to Generate Specifications | #60993 | 18″ x 18″ x 2.5″ Thick |
