The 600 has many available options so the chair can be fitted to the user, or it could be setup to be used in a multi – use facility. From the least involved client to the most involved , this chair is readily able to fit their needs.
The 600, Rehab Shower/Commode Chair, has features that address the needs of the rehabilitating, long-term care, home care clients, and care givers. Frame widths are available from 18-22″ and wheel options include 4 casters, 20″ or 24″ rear wheels. There are many seat options, including several 4-way adjustable seats for seat opening access in any direction. This chair is designed to make those daily activities just a little bit easier.
| Seat Width | 18″ | 18″ | 20″ | 22″ |
| Weight Capacity | 350lbs. | 350lbs. | 350lbs. | 350lbs. |
| Width between Arm Rests Flip-Up with Pad | 18.25″ | 18.25″ | 20.25″ | 22.25″ |
| Width between Arm Rests – Arm Troughs | 16.5″ | 16.5″ | 18.5″ | 20.5″ |
| Seat Depth | 18″ | 20″ | 18″ | 18″ |
| Seat Height From Floor to Top of Seat | Front to Back 24″ Wheels – 23″ – 21.25″ 5″ Rear Casters – 23″ – 22.25″ | Front to Back 24″ Wheels – 23″ – 21.25″ 5″ Rear Casters – 23″ – 22.25″ | Front to Back 24″ Wheels – 23″ – 21.25″ 5″ Rear Casters – 23″ – 22.25″ | Front to Back 24″ Wheels – 23″ – 21.25″ 5″ Rear Casters – 23″ – 22.25″ |
| Usable Seat Depth w/Solid Back | 18″ | 20″ | 18″ | 18″ |
| Leg Rest Range – Gooseneck | 14″ – 20.25″ | 14″ – 20.25″ | 14″ – 20.25″ | 14″ – 20.25″ |
| Leg Rest Range – Gooseneck w/ Padded Footplate | 12.75″ – 19.25″ | 12.75″ – 19.25″ | 12.75″ – 19.25″ | 12.75″ – 19.25″ |
| Leg Rest Range – Elevating (Up) | 17″ – 24″ | 17″ – 24″ | 17″ – 24″ | 17″ – 24″ |
| Leg Rest Range – Elevating (Up) w/ Padded Footplate | 15.75″ – 22.75″ | 15.75″ – 22.75″ | 15.75″ – 22.75″ | 15.75″ – 22.75″ |
| Leg Rest Range – Elevating (Down) | 16.5″ – 23.5″ | 16.5″ – 23.5″ | 16.5″ – 23.5″ | 16.5″ – 23.5″ |
| Leg Rest Range – Elevating (Down) w/ Padded Footplate | 15.25″ – 22.25″ | 15.25″ – 22.25″ | 15.25″ – 22.25″ | 15.25″ – 22.25″ |
| Leg Rest Range – One Piece Footplate | 19″ | 19″ | 19″ | 19″ |
| Arm Height from Top of Seat – Flip Up w/Pad | 8″ | 8″ | 8″ | 8″ |
| Arm Height from Top of Seat – Arm Troughs | 8.25″ | 8.25″ | 8.25″ | 8.25″ |
| Back Height from Top of Seat | 16.5″ | 16.5″ | 16.5″ | 16.5″ |
| Gap Between Top of Seat and Bottom of Back | 8.5″ | 8.5″ | 8.5″ | 8.5″ |
| Seat to Back Angle | 11° | 11° | 11° | 11° |
| Under Seat Height Clearance | 18.25″ | 18.25″ | 18.25″ | 18.25″ |
| Under Seat Width Clearance w/ 24″ Wheels | 14″ | 14″ | 16″ | 18″ |
| Under Seat Width Clearance w/ 5″ Rear Casters | 15.75″ | 15.75″ | 17.75″ | 19.75″ |
| Overall Width w/ 24″ Wheels | 25.25″ | 25.25″ | 27.25″ | 29.25″ |
| Overall Width w/ 5″ Rear Casters & Std. Arms | 22.5″ | 22.5″ | 24.5″ | 26.5″ |
| Overall Width w/ 5″ Rear Casters & Arm Troughs | 26.5″ | 26.5″ | 28.5 | 30.5 |
| Overall Min Length w/ 5″ Rear Casters | 41.5″ | 43.5″ | 41.5″ | 41.5″ |
| Overall Min Length w/ 24″ Rear Wheels | 42.5″ | 44.25″ | 42.5″ | 42.5″ |
| Back of Unit to Start of Commode Opening with 24″ Wheels | 15.5″ | 15.5″ | 15.5″ | 15.5″ |
| Back of Unit to Start of Commode Opening with 5″ Rear Casters | 14.75″ | 14.75″ | 14.75″ | 14.75″ |
| Turning Radius – Min w/ 5″ Rear Casters | 21″ | 22″ | 22″ | 22.5″ |
| Seat Used to Generate Specifications | #60905 | 22″ x 18″ x 2″ Thick |
